PAL Devices Data Book and Design Guide.

AMDs programmable logic devices (PLDs) provide designers with the flexibility they need to deal with change. From the earliest days of PLDs to the present, designers have relied on AMD PLD solutions to quickly bring their products to market. AMD PLDs help designers manage changing specifications, new standards, and shorter product life cycles. AMD offers a complete portfolio of fast (5-ns teo), low-power (quarter power and zero power), and low-voltage (3.3-V Vcc) industry-standard PLDs. An early pioneer in programmable logic devices, AMD set industry standards as the inventor of the Programmable Array Logic (PAL) device, 22V10 macrocell, and MACH family of CPLDs. AMD has continually brought designers leading-edge solutions through innovation in programmable logic architecture and leadership in process technology. AMD currently leads the industry with advanced electrically-erasable CMOS processes. In addition to exceptional devices, AMD eases the design process through the Universal Software Program. Designers can select software tools directly from AMD to meet their specific needs. Furthermore, through a partnership with MINC, Inc., AMD PLDs are supported by all of the leading universal software tools on PCs and workstations. In this way, designers can quickly and easily use the tools they know on the platforms they own. In this data book are data sheets for EECMOS and bipolar PAL devices. The second part of this publication is a design guide for new programmable logic users. Also inside the data book are short data sheets for the MACH family of complex programmable logic devices.
